Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > Intelligent Computing > AMD AI Server

AMD AI Server

Integrated Training and Inference

Powerful computing performance and exceptional scalability

Supports 2 AMD EPYC Turin 9005 series processors, compatible with Genoa 9004 series processors, with a maximum TDP of 500W. Supports up to 24 DDR5 memory slots with frequencies of 4800/6400MHz and a 75% increase in memory bandwidth. Equipped with 2 PCIe 3.0 M.2 NVMe SSDs (2280). CPU-GPU switch expansion mode supports 600W dual-width GPU cards. Supports SATA/SAS/NVMe tri-mode hard drive configurations to meet high-speed transmission and data storage needs.

Applicable Solutions

Artificial Intelligence | Cloud Gaming | Virtualization | Big Data Analytics | Digital Twin

Add to Compare

Product Overview Product Specifications Relevant Information

New Architecture, Ultimate Performance

Supports 1 or 2 AMD EPYC Turin series processors, compatible with 1 or 2 AMD EPYC Genoa series processors. Supports 24 DDR5 6000/4800MT/s ECC memory, with a 75% increase in memory bandwidth. Offers GPU-CPU direct connection or Switch expansion configurations for maximum multi-GPU compute power.

Flexible Topology, Critical Applications

CPU-GPU Switch expansion supports up to 10 dual-width GPU cards running at high speeds and stability. CPU-Switch interconnect supports PCIe 5.0 x32, enabling high-bandwidth communication.

Rich Ecosystem, Stable and Reliable

Supports AI acceleration cards from both international and domestic brands. Redundant design of critical system components and modularization of functional parts enhance reliability and maintainability. Smart remote management and fault diagnosis ensure 24/7 efficient and stable operation.

System Model	G6460A5
Processor	Supports 1 or 2 AMD EPYC Turin series processors, compatible with AMD EPYC Genoa series processors
GPU Card	Supports up to 8 dual-width GPU cards
Memory	24 DDR5 memory slots, supporting DDR5 4800/6400MHz memory
Storage Controller	2 PCIe3.0 M.2(2280/22110）
Storage	Supports 12 3.5″ /2.5" SAS/SATA/NVMe hot-swappable hard drives
I/O Ports	Front: 2 USB 3.0, 1 Power Button, 1 Reset Button, 1 Hard Drive Indicator, 1 System Fault Indicator, 2 Network Indicators Rear: 1 VGA, 2 USB 3.0, 1 Management Port, 2 RJ45 Network Ports, 1 Serial Port
PCIe Expansion	20 PCIe5.0 MCIO(x8) Supports expansion of 8 x PCIe 5.0 x16 dual-width full-height full-length slots and 5 x PCIe 5.0 x16 single-width full-height full-length slots
Power Supply	Supports 2000W/2200W/2700W CRPS N+1 redundant power supply (configured based on actual power requirements)
Fan	Standard 12 x 6056 hot-swappable N+1 redundant fans
Management	1 x RJ45 management network port, IPMI 2.0
Security	Supports TPM 2.0 module, chassis open alarm, and BMC/BIOS redundancy
Operating System	Microsoft Windows Server, RedHatEnterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VmwareEXSi
Server Size	850 x 444 x 176.5 mm (D * W * H)
Working Temperature	Operating Temperature: 5ºC - 35ºC (without direct sunlight); Storage Temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
