Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > Intelligent Computing > AS4110G-D04R-G3

AS4110G-D04R-G3

Storage-Compute Convergence

Supports 1 or 2 Gen3 Intel® Xeon® Scalable ICE Lake processor / 16 DDR4 slots, supports 2666/2933/3200MHz DDR4 memory / Supports 8 hot-swap SAS/SATA (HDD/SSD）

Applicable solution

cloud computing

Add product comparison

Product Overview Product specifications Relevant information

Ultra high computing power

Support Intel® Xeon® Scalable Series processors (Ice Lake), support 2 high-power GPUs, and 1 M.2 interfaces on the motherboard, enabling ultra-high computing power; at the same time, the core, frequency, cache, and interconnect channel have been comprehensively enhanced.It also adopts DDR4 memory technology and supports 2TB memory expansion capability, which can be expanded on demand to meet application requirements of ultra-high computing power such as digital currency, cloud computing, big data, and virtual computing.

Good heat dissipation

Unique design of the front GPU bin allows the GPU to absorb more cool air, and has a separate GPU cooling air duct, ensuring the stable operation of server.

Ultra GPU density

The 4U system supports up to 10* 2-width & full-height GPU cards. Compatible with NVIDIA GTX & RTX series. It provides various PSU modes without changes & excellent architecture for incredible computing.

AI intelligent remote management

IPMI remote management enables real-time monitoring of the system and real-time operations including switching on and off, ensuring that system managers to maintain the system in a timely manner; realize a true redundant architecture, including fans, power supplies, and storage.

System model	AS4110G-D04R-G3
Processor	1 or 2 Intel® Xeon® Series Gen3 Scalable processors
Chipset	Intel® C621 A series dedicated processor chipset
Memory	16 DDR4 slots, supports DDR4 2666/2933/3200MHz LRDIMM/ RDIMM memory
Storage controller	Internal PCH supports RAID 0\1\10&5 (for Windows only)
Storage	Front: 4x 3.5" /2.5" SAS/SATA hot-swap hard drives Rear 2x 2.5" SAS/SATA hard drives Rear optional added 2x 2.5" SAS/SATA or U.2 hard drives Internal storage: 1 M.2 (PCIe3.0 x4) interface, 3 MiniSAS HD interfaces, 2 SATA DOM interfaces
Network	Onboard 2 Gigabit RJ45 network ports
I/O ports	Front: 2 USB3.0; Rear: Integrated 2 Gigabit network ports, 1 independent IPMI management network port, 2 USB3.0 ports, 1 VGA port
PCIe Extension	Front PCIe4.0 x16 slots; Rear 7 half-height PCIe x16 slots {support 4 PCIe 3.0x8 (in PCIe 3.0 x16 slot) and 3 PCIe 4.0x16; Optional 2 PCIe 3.0x8 (in PCIe 3.0 x16 slot), 1 PCIe 3.0x16, and 3 PCIe 4.0x16}
Power Supply	1200W, 1300W, 1600W, 2000W, 2200W hot-swap 3+1 redundant power
Fan	11x 8038 hot-swap fans
Administration	IPMI2.0
System fan	10 full-length full-height dual-width GPU cards
Security	TPM; chassis upper cover lock
Operating system	Microsoft Windows Server、Red Hat Enterprise Linux、 SUSE Linux Enterprise Server、CentOS、Ubuntu
Server Size	790 x 433 x 176.5mm (D x W x H)
Working temperature	Operating temperature: 5ºC - 35ºC (indoor) Storage temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
