Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > Chassis > RMC4110-790-HTF

RMC4110-790-HTF

Safe and stable

Storage-Compute Convergence

MB spec: 12”x 13”& below / 12Gb/s passive BP. Fits SAS3.0/SATA3.0 Drive / 3+1 redundant PSU / Intelligent thermal control, up to 11x 8038 hot-swap fans / Supports 10 full-height, full-length, dual-width GPU cards

Add product comparison

Product Overview Product specifications Relevant information

4U height, 10 dual-width GPU cards
Ability of real-time high-speed parallel and floating-point computing
For HPC, big data analysis, 3D graphics applications, video decoding, deep learning.

Platform conversion

Compatible with various MB specs (EEB (12*13) / CEB (12*10.5) / ATX (12*9.5)/Micro ATX), the platform can be customized on demand.The front-end supports 10* 2.5" hot-swap hard disks, and the rear supports up to 4* 2.5" hot-swap.It provides SAS card & RAID data protection support (optional).

Ultra GPU density

The 4U system supports up to 10* 2-width & full-height GPU cards. Compatible with NVIDIA GTX & RTX series. It provides various PSU modes without changes & excellent architecture for incredible computing.

Good heat dissipation

Unique design of the front GPU bin allows the GPU to absorb more cool air, and has a separate GPU cooling air duct, ensuring the stable operation of server.

System model	RMC4110-790-HTF
Chassis form	Rackmount
Chassis height	4U
Adapting motherboard	EEB(1213)/CEB(1210.5)/ATX(12*9.5)/Micro ATX
Power supply type	Supports 3+1 redundant power supplies (1200W, 1300W, 1600W, 2000W, 2200W)
Backplane	12Gb/s passive backplane
Disk bit	Supports SGPIO; compatible with SAS3.0/SATA3.0 hard drives; front 10x 2.5” hot-swap hard driver bays, optional rear 4x 2.5” hot-swap hard driver bays(SAS3.0/ SATA3.0/U.2)
HDD shockproof	The hard drive rack adopts EMI spring design, unique shockproof fan design, reduces the resonance between the fan and the hard disk, and does not affect the hard drive I/O speed
System fan	Supports intelligent-temperature control, 11x 8038 hot-swap fans
Expansion card slot	Front 10x full-height double-width PCIe expansion slots, rear 7x half-height single-width PCIe expansion slots
Security	TPM/TCM (Requires motherboard support)
Front panel control	2 USB2.0, 1 power switch, 1 reset button, 1 system failure indicator, 1 hard disk indicator, 2 network indicators
Slide rail	Optional
Air cowl	Optional
Front cover	Optional
Product material	Imported SGCC (galvanized steel sheet), ABS panel and perforated mesh
Chassis size	790mm433mm176.5mm (D* W* H)
Gross weight of chassis	30kg（Net weight）/ 36kg（Gross weight）
Package size	985mm585mm325mm (D* W* H）

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
