Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Computing > Intel > Dual-Socket Server

Dual-Socket Server

Dual-Socket High-Performance Computing

Ideal for virtualization, cloud computing, big data processing, high-performance computing, distributed storage, enterprise markets, or telecom applications. Supports 2 fourth/fifth-generation Intel® Xeon® Scalable processors, DDR5 4400/4800/5600 MHz ECC memory, and 12 PCIe 5.0 slots, delivering robust computing performance and flexible configurations to meet various industry application needs.

Applicable Solutions

Virtualization, cloud computing, big data processing, high-performance computing, distributed storage, enterprise markets, telecom services

Add to Compare

Product Overview Product Specifications Relevant Information

Comprehensive Performance Enhancement

Supports 1 or 2 fourth/fifth-generation Intel® Xeon® Scalable processors, with up to 60 cores per processor, enhancing general performance by 15%. Supports 4 UPI 2.0 buses, each with a maximum UPI rate of 16 GT/s, increasing CPU communication speed by 25%. Supports 32 DDR5 4400/4800/5600 MHz ECC memory modules, boosting memory bandwidth by 50%. Features PCIe standard slots and OCP 3.0 slots, fully supporting PCIe 5.0 protocol, doubling bandwidth.

Superior Storage and Flexible Expansion

Supports up to 12 mixed 3.5″/2.5″ SATA/SAS hard drives, providing users with massive data storage capabilities. Supports up to 10 PCIe 5.0 standard slots and 2 PCIe 5.0 OCP 3.0 slots, meeting expansion needs.

Convenient Management and Intelligent Maintenance

Offers iKVM remote management functionality, allowing remote management via keyboard, monitor, and mouse for greater convenience. Modular design enables non-stop replacement of peripheral components, enhancing efficiency. Automatically saves fault logs, supports remote diagnostics for quicker problem resolution. Real-time monitoring of critical component status enables automatic fault reporting, making the system smarter.

System Model	SL201-D12R-G4
Processor	Supports 1 or 2 4th/5th Generation Intel® Xeon® Scalable Processors, with a maximum TDP of 350W
Chipset	Intel® C741 series server-specific chipset
Memory	32 DDR5 memory slots, supporting DDR5 RDIMM 4400/4800/5600MHz memory
Storage Controller	3 Mini SAS HD ports, 2 SATA/NVMe M.2 SSD ports, 14 MCIO ports
Storage	Support 12 hot-swappable 3.5/2.5" SAS/SATA hard drives in the front and 2 optional 2×2.5" hard drive modules in the rear
Network	Supports 2 OCP 3.0 network cards
I/O Ports	Front ports: 1 VGA, 2 USB3.0 Rear ports: 1 VGA, 1 COM port, 2 USB3.0, 1 RJ45 Gigabit management network port
PCIe Expansion	PCIe expansion form 6x PCIe full-height slots, 4x PCIe half-height slots, 2x OCP 3.0 slots PCIe expansion specifications Riser1/2: 1x full-height PCIe 5.0 x16+2x full-height PCIe 5.0 x8 2x full-height PCIe 5.0 x16 Riser3/4: 2x half-height PCIe 5.0 x8 1x half-height PCIe 5.0 x16 OCP: 2x OCP 3.0(PCIe 5.0 x8)
Power Supply	Supports AC 220V 800W, 1300W, 1600W, 2000W, 2200W, 2600W redundant power supplies
Fan	Standard 4 hot-swappable N+1 redundant fans, supporting 8038/8056 specifications
Management	1 dedicated RJ45 management port
Security	Supports TPM2.0 module, chassis intrusion alert, BMC/BIOS redundancy
Operating System	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu
Server Size	799433.487.6mm(DWH)
Working Temperature	Operating temperature: 5°C - 35°C (without direct sunlight) Storage temperature: -40°C - 70°C

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
