Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Computing > Dual-Socket General Server

Dual-Socket General Server

Dual-Socket High-Performance Computing

Suitable for applications such as artificial intelligence, cloud computing, virtualization, and enterprise digitalization. Supports 1 or 2 fourth- or fifth-generation Intel® Xeon® Scalable processors, with up to 64 cores per processor. Supports 16 DDR5 5600MT/s ECC memory modules and up to 9 PCIe 5.0 low-profile, full-length, single-width slots to meet expansion needs.

Applicable Solutions

Artificial Intelligence, Cloud Computing, Virtualization, Enterprise Digitalization

Add to Compare

Product Overview Product Specifications Relevant Information

Significantly Enhanced Computing Performance

Supports 1 or 2 fourth- or fifth-generation Intel® Xeon® Scalable processors, with up to 64 cores per processor. Features 4 UPI 2.0 links with speeds up to 16 GT/s per link. Supports 16 DDR5 5600MT/s ECC memory modules, delivering a 75% increase in memory bandwidth. Fully supports the PCIe 5.0 interface, doubling bandwidth.

Flexible Expansion with Superior Storage

Supports up to twelve 3.5"/2.5" drives, offering massive data storage capacity. Equipped with up to nine PCIe 5.0 low-profile, full-length, single-width slots to meet a wide range of expansion needs.

Effortless Management and Intelligent Maintenance

Offers iKVM remote management for convenient access via keyboard, video, and mouse. Modular design allows non-disruptive replacement of peripheral components, improving efficiency. Automatically logs failure events and supports remote diagnostics for faster troubleshooting. Monitors key component status in real time with automated fault reporting for smarter maintenance.

System Model	AS201-D12RE-G4
Processor	Supports 2 fourth- or fifth-generation Intel® Xeon® Scalable processors with a maximum TDP of 350W.
Chipset	Intel® C741 Series Server-Specific Chipset
Memory	16 DDR5 memory slots, supporting DDR5 4400/4800/5600 MHz RDIMM modules
Storage Controller	2 M.2 (PCIe 5.0 x4) slots, 3 MiniSAS HD ports, and 2 SATA DOM ports
Storage	Front supports up to 12 hot-swap 3.5"/2.5" SATA/SAS drives
I/O Ports	Front Ports: 2 USB 3.0, 1 VGA Rear Ports: 1 VGA, 1 COM port, 2 USB 3.0, 1 management network port, 2 RJ45 network ports
PCIe Expansion	Rear Optional: Supports 9 low-profile, full-length, single-width PCIe 5.0 slots Rear Optional: Supports 1 full-height, full-length, dual-width PCIe 5.0 slot and 5 low-profile, full-length, single-width PCIe 5.0 slots
Power Supply	800W/1300W/1600W/2000W CRPS 1+1 Redundant（1+1）
Fan	Standard 4 hot-swap 8038 N+1 redundant fans
Management	1 RJ45 management network port
Security	Supports TPM/TCM hardware encryption modules, BMC remote access encryption, and BIOS access encryption
Operating System	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu
Server Size	745 x 444 x 87.6 mm (D * W * H)
Working Temperature	Operating Temperature: 5ºC – 35ºC (without direct sunlight); Storage Temperature: -40ºC – 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
