Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Computing > Dual-Socket Server

Dual-Socket Server

Storage and Computing Convergence

AMD dual-socket general rack server, built on the AMD fourth-generation processor platform, supports 24 DDR5 memory slots and 10 PCIe expansion slots. It is compatible with two high-performance full-length, full-height dual-width GPUs. This high-performance server offers flexible configurations and is suitable for virtualization, cloud computing, big data processing, high-performance computing, distributed storage, enterprise markets, and telecommunications applications.

Applicable Solutions

Cloud Computing, Virtualization

Add to Compare

Product Overview Product Specifications Relevant Information

Modular Design

The rack-mounted general chassis features a modular design with various rear panel options to quickly meet customer needs. Modular components for fans, power supplies, and hard drives enhance system reliability and cooling performance, making maintenance more convenient.

Strong Expandability

Supports 8 PCIe 5.0 and 2 PCIe 4.0 high-speed expansion slots, offering rich expansion capabilities. Multiple 12Gb SAS/SATA/NVMe adaptive backplanes are available for flexibility and convenience. Expansion needs can be customized with adapter cards.

High Performance

Supports two AMD EPYC 9004 (Genoa) series processors. It features 24 DDR5 memory slots with support for 4800 and 4400 DDR5 RDIMM memory. The motherboard natively supports NVMe (M.2) cache interfaces to meet the high computing demands of cloud computing, big data, and virtual computing.

Smart Power Supply and Temperature Control

Equipped with 1+1 redundant power supplies that support hot-swappable replacement to ensure system stability. Features intelligent temperature-controlled fan modules with hot-swappable capabilities and excellent shock-resistant design.

System Model	SR201-D25RE-G2
Processor	Supports 2 AMD EPYC 9004 (Genoa) series processors
Memory	24 DDR5 memory slots, supporting 4800/4400 DDR5 RDIMM memory
Storage Controller	Onboard with 3 MiniSAS SFF-8643 connectors, 2 SATA ports, 2 M.2 slots (PCIe 5.0 x4 signal, 2280), and 2 slimline x8 (PCIe 4.0 x8 signal) connectors
Storage	Front: 25 x 2.5” SAS/SATA hot-swappable hard drives Rear: Optional support for 2 x 2.5” SAS/SATA/NVMe hot-swappable hard drives
Network	Onboard 2 x 1GbE (RJ45)
I/O Ports	Front: 1 x VGA, 2 x USB 3.0 Rear: 1 x VGA, 1 x COM port, 2 x USB 3.0, 1 x RJ45 Gigabit management port, 2 x Gigabit RJ45 ports
PCIe Expansion	Riser1/Riser2: 2 x PCIe 5.0 x16 Riser3: 2 x PCIe 5.0 x8 Riser4: 1 x PCIe 4.0 x16 or 2 x PCIe 4.0 x8
Power Supply	Supports hot-swappable redundant power supplies of 800W, 1300W, 1600W, 2000W, or 2200W (adapted according to actual power requirements)
Fan	Standard configuration: 4 hot-swappable redundant 8038 fans Optional: 4 hot-swappable redundant 8056 fans
Management	1 management RJ45 network port IPMI 2.0
Security	TPM/TCM (optional) Chassis cover intrusion detection Locked upper cover of chassis
Operating System	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu
Server Size	748 x 433.4 x 87.6 mm (D * W * H)
Working Temperature	Operating Temperature: 5ºC - 35ºC (without direct sunlight) Storage Temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
