Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Computing > Dual-Socket Server

Dual-Socket Server

General High-Performance Server

AMD dual-socket rack-mounted server utilizing the AMD fourth-generation processor platform, supporting DDR5 memory, PCIe 5.0 expansion slots. Compatible with two GPUs such as RTX4090, A800 series, its multicore and high-performance features make it well-suited for a wide range of applications, including cloud computing, virtualization, and AI.

Applicable Solutions

Cloud Computing, Virtualization

Add to Compare

Product Overview Product Specifications Relevant Information

Modular Design

A rack-mounted general-purpose chassis with a variety of modular rear windows to choose from, allowing for quick responses to customer needs. The fans, power supply, and hard drives all feature modular design, enhancing the overall reliability and heat dissipation performance of the system, facilitating easy maintenance.

Strong Expandability

Supports8 PCIe 5.0and2 PCIe4.0 high-speed expansion slots, providing abundant expansion capabilities. Multiple 12Gb SAS/SATA/NVMe adaptive backplanes are available, offering flexibility and convenience. Custom expansion needs can be tailored to customers through adapter cards.

High Performance

Supports two AMD EPYC 9004 (Genoa) series processors; accommodates 24 DDR5 memory slots, supporting 4800 and 4400 DDR5 RDIMM memory slots. The motherboard natively supports NVMe (M.2) cache interfaces, meeting the demands of high computing power applications such as cloud computing, big data, and virtual computing.

Intelligent Power Supply and Temperature Control

Utilizes a 1+1 redundant power supply with hot-swappable capabilities to ensure system stability. Incorporates an intelligent temperature control fan module, supporting hot-swappable replacements and featuring excellent anti-vibration design.

System Model	SR201-D08R-NV-G2
Processor	Supports two AMD EPYC 9004 (Genoa) series processors
Chipset	/
Memory	24 DDR5 memory slots, support 4800/4400 DDR5 RDIMM memory
Storage Controller	Onboard 3 MiniSAS SFF-8643 connectors, 2 SATA interfaces, 2 M.2 interfaces (PCIe5.0 X4 signal, 2280), 2 slimline x8 (PCIe4.0 x8 signal) interfaces
Storage	Front: 8 3.5/2.5” SAS/SATA/NVMe hot-swappable hard drives Rear: optional 2 2×2.5” SAS/SATA/NVMe hot-swappable hard drives
Network	2 x 1GbE (RJ45) onboard
I/O Ports	Front: 1 VGA, 2 USB3.0 Rear: 1 VGA, 1 COM port, 2 USB3.0, 1 RJ45 Gigabit management network port, 2 Gigabit RJ45 network port
PCIe Expansion	Riser1/Riser2：2x PCIe5.0 x16 Riser3：2x PCIe5.0 x8 Riser4：1x PCIe4.0 x16 or 2x PCIe4.0 x8
Power Supply	Supports 800W/1300W/1600W/2000W/2200W hot-swappable redundant power supply (adapted according to actual power)
Fan	Standard 4 x 8038 hot-swappable redundant fans Optional 4 x 8056 hot-swappable redundant fans
Management	1 RJ45 management network port IPMI2.0
Security	TPM/TCM (optional) Chassis cover opening intrusion detection Locking the chassis upper cover
Operating System	Microsoft Windows Server、Red Hat Enterprise Linux、 SUSE Linux Enterprise Server、CentOS、Ubuntu
Server Size	748 x 433.4 x 87.6mm (depthwidthheight)
Working Temperature	Working temperature: 5ºC - 35ºC (without direct light) Storage temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
