Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Computing > Dual-Socket Server

Dual-Socket Server

Dual-Socket High Performance Computing

Designed for cloud computing, HPC (High-Performance Computing), virtualization, telecommunications, big data analytics, and more. Supports 4th/5th generation Intel® Xeon® Scalable processors, DDR5 4800MHz ECC memory, and 12 PCIe 5.0 slots, delivering robust computational performance and versatile configurations to meet various industry needs.

Applicable Solutions

Cloud computing, HPC, virtualization, telecommunications, big data analytics

Add to Compare

Product Overview Product Specifications Relevant Information

Comprehensive Performance Enhancement

Supports 4th/5th generation Intel® Xeon® Scalable processors, with a maximum of 60 cores for a 15% improvement in general performance. Features 4 UPI 2.0 buses with speeds of up to 16GT/s, resulting in a 25% increase in CPU communication rates. Accommodates 32 DDR5 4800MT/s ECC memory modules, offering a 50% boost in memory bandwidth. Supports PCIe standard slots and OCP 3.0 slots, fully compliant with PCIe 5.0 protocol for a 100% bandwidth increase.

Flexible Storage Expansion

Can accommodate up to 12 3.5"/2.5" SATA/SAS/GEN5 U.2 hard drives, providing extensive data storage capacity. Features up to 10 PCIe 5.0 standard slots and 2 PCIe 5.0 OCP 3.0 slots to meet expansion requirements.

Convenient Management and Intelligent Maintenance

Offers iKVM remote management functionality, allowing remote management through a keyboard, display, and mouse for added convenience. Features modular design, enabling non-stop replacement of peripheral components for greater efficiency. Automatically saves fault logs, supports remote diagnosis of issues for faster resolution, and provides real-time monitoring of critical component statuses with automatic fault reporting for enhanced intelligence.

System Model	SL201-D12R-NV-G4
Processor	Supports 1 or 2 4th/5th generation Intel® Xeon® Scalable processors with a maximum TDP of 350W.
Chipset	Intel® C741 series server-specific chipset
Memory	32 DDR5 memory slots, support DDR5 RDIMM-3DS/RDIMM 4400/4800MHz memory
Storage Controller	3 Mini SAS HD interfaces and 2 SATA M.2 SSD interfaces
Storage	Front supports 12 hot-swappable 3.5/2.5" SAS/SATA/U.2 hard drives Rear can optionally support 2 modules of 2x 3.5" hard drives or 2 modules of 2x 2.5" hard drives
Network	Supports 2 OCP 3.0 network cards
I/O Ports	Front: 1 VGA, 2 USB 3.0 ports Rear: 1 VGA, 1 COM port, 2 USB 3.0 ports, 1 RJ45 Gigabit management network
PCIe Expansion	PCIe Expansion Configuration 6 full-height PCIe slots, 4 half-height PCIe slots, 2 OCP 3.0 slots PCIe Expansion Specifications Riser1/2: 1 full-height PCIe 5.0 x16, 2 full-height PCIe 5.0 x8, 2 full-height PCIe 5.0 x16 Riser3/4: 2 half-height PCIe 5.0 x8, 1 half-height PCIe 5.0 x16 OCP: 2 OCP 3.0 (PCIe 5.0 x8)
Power Supply	Supports AC 220V redundant power supplies with various wattages, including 800W, 1300W, 1600W, 2000W, 2200W, and 2600W, based on actual power requirements
Fan	Standard 4*8038/8056 hot-swappable N+1 redundant fans
Management	1 dedicated RJ45 management network port, IPMI 2.0
Security	Supports TPM 2.0 module, chassis intrusion alarm, BMC/BIOS redundancy
Operating System	Microsoft Windows Server、Red Hat Enterprise Linux、SUSE Linux Enterprise Server、CentOS、Ubuntu
Server Size	799433.487.6mm (depthwidthheight)
Working Temperature	Working temperature: 5ºC - 35ºC (without direct light); Storage temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
