Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Computing > Dual-Socket Server

Dual-Socket Server

Storage-Compute Convergence

Support 1 or 2 AMD EPYC 7003 series, compatible with AMD EPYC 7002 & 7001 series, CPU TDP≤240W / 32 DDR4 slots, support 2666/2933/3200MHz DDR4 memory / Supports 4 hot-swap SAS/SATA (HDD/SSD)

Applicable solution

cloud computing, Virtualization

Add to Compare

Product Overview Product Specifications Relevant Information

Modular design

General rackmount chassis; a variety of modular rear windows for rapid response to customer needs; fans, power supplies, and hard drives are all modular designed to improve system reliability and heat dissipation, and facilitate future maintenance.

Strong scalability

Supports 2 PCle4.0/3.0 high-speed expansion slots to provide rich expansion capabilities. Multiple 12Gb SAS/SATA adaptive backplanes are available, offering flexibility and convenience. Customized expansion requirements are available for customers via adapter cards.

High performance

Support single/dual-socket AMD Milan EPYC 7003 processors, based on Zen 3 cores, each core has up to 32MB of L3 cache, 19% single-core performance improvement; support 16 dual-channel DDR4/2666/2933 memory slots. Motherboard supports NVMe(M.2) cache interface to meet high computing requirements for cloud computing, big data, and virtual computing.

Intelligent power supply and temperature control

Adopt 1+1 redundant power supply, support hot-swap replacement, and ensure the stability of the system; adopt intelligent temperature-controlled fan module, support hot-swap replacement, and has excellent shock resistance design.

System Model	SR101-D04R
Processor	Support 1 or 2 AMD EPYC 7003 series, compatible with AMD EPYC 7002 & 7001 series, CPU TDP≤240W
Chipset	/
Memory	32 DDR4 slots, support 2666/2933/3200MHz DDR4 memory
Storage Controller	2 PCIe 4.0/3.0 x 2 M.2 ports 4 SATA 7PIN slots (2 of them support SATA DOM) 3 MiniSAS HD ports
Storage	Front: 4x 3.5"/2.5" SAS/SATA hot-swap hard drives
Network	2x 1GbE (RJ45) onboard
I/O Ports	Front: 1 VGA, 2 USB3.0 Rear: 1 VGA, 1 COM port, 2 USB3.0, 1 management network port, 2 RJ45 network ports OCP slot: 1 OCP 3.0 (PCIe x 8)
PCIe Expansion	2 full-height PCIe expansion slots
Power Supply	Support 550W, 800W, 1300W, 1600W, 2200W redundant power (adapt according to the actual power)
Fan	Standard 7x 4056 fans
Management	1 dedicated RJ45 management network port IPMI2.0
Security	TPM/TCM (optional) Chassis open intrusion detection Locked upper cover of chassis
Operating System	Microsoft Windows Server、Red Hat Enterprise Linux、 SUSE Linux Enterprise Server、CentOS、Ubuntu
Server Size	748 x 433.4 x 43.6mm (D x W x H)
Working Temperature	Operating temperature: 5ºC - 35ºC (indoor) Storage temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
