Dual-Socket Server

Storage-Compute Convergence

Storage-Compute Convergence

Supports 1 or 2 Gen3 Intel® Xeon® Scalable ICE Lake processor / 32 DDR4 slots, supports 2666/2933/3200MHz DDR4 memory / Supports 12 hot-swap SAS/SATA/NVMe(HDD/SSD/U.2)

Applicable solution

Cloud Computing, Cloud Storage, AI Vision, Big Data Processing
Product Overview Product Specifications Relevant Information

Ultrahigh Computing

Supports the full range of Intel ICE Lake processors, TDP up to 270W, 40 cores. Dominant frequency up to 3.6GHz.2* high-power GPUs. Improved kernel, frequency, cache & interconnection channel. DDR4 technologies, 12TB memory expansibility for digital currency, cloud computing, big data & virtual computing.

Massive Storage & High Scalability

Up to 32* DIMM slots.Up to 12* 3.5”+rear 4* 3.5” or 4* 2.5” hot-swap hard disks, providing excellent data storage & expansibility.11* PCIe expansion slots.

Availability & Security

Full modular hard disk, PSU, fan & PCIe show the changeable, replaceable, expandable & low power system. Newest BMC tech to simplify maintenance, improve availability, ensure stable operation & reduce downtime. RAID Level by various RAID controllers for data integrity.

AI Remote Management

IPMI remote management enables real-time monitoring of the system and operation incl. power on/off, to ensure system’s maintenance.Truly Redundant architecture, incl. fan, PSU, storage.

System Model SL201-D12R/-NV-G3
Processor Support 1 or 2 Gen3 Intel® Xeon® Scalable ICE Lake processors, 83xx/63xx/53xx/43xx processors, maximum CPU TDP 270W
Chipset Intel® C621 A series dedicated processor chipset
Memory 32* DDR4 slots, supports 2666/2933/3200MHz DDR4 memory
Storage Controller Internal PCH supports RAID 0\1\10&5
External HBA (not RAID): 12 Gbps SAS HBA
Storage Front port: 12* 3.5/2.5" SAS/SATA /NVMe hot-swap hard drives
Optional 4* 3.5" SAS/SATA or 4x 2.5" SAS/SATA/U.2 hard drives
Internal storage: 2* PCIe 4.0 x4 M.2 ports, 2 SATA 7PIN slots (support SATA DOM), 3* MiniSAS HD ports
Network 2* 1GbE (RJ45) onboard
I/O Ports Front port: 1* VGA, 2 USB3.0
Rear: 1* VGA, 2* USB3.0, 1 management network port, 2 RJ45 network ports
OCP slot: 1 OCP 3.0 (PCIe x 8)
PCIe Expansion Riser1:1*full-height PCIe 4.0 x16、2*full-height PCIe 4.0 x8 or 2*full-height PCIe 4.0 x16
Riser2:1*full-height PCIe 4.0 x16、2*full-height PCIe 4.0 x8 or 2*full-height PCIe 4.0 x16
Riser3:1*half-height PCIe 4.0 x16 or 1*half-height PCIe 3.0 x8、1*half-height PCIe 3.0 x8(in x16 Slot)
Riser4:1*half-height PCIe 3.0 x8、1*half-height PCIe 3.0 x8(in x16 Slot)
OCP:1*OCP 3.0(PCIe 3.0 x8)
Power Supply Support 550W, 800W, 1300W, 1600W, 2000W, 2200W redundant power
Fan 4* 8038 N+1 Redundant hot-swap fans, optional 4* 8056 N+1 Redundant hot-swap fans
Management Onboard iBMC management module, support IPMI, SOL, KVM Over IP, virtual media and other management features
Security TPM/TCM (optional) ,Chassis open intrusion detection ,Locked upper cover of chassis
Operating System Microsoft Windows Server、Red Hat Enterprise Linux、 SUSE Linux Enterprise Server、CentOS、Ubuntu
Server Size 748 x 433.4 x 87.6mm (D x W x H)
Working Temperature Operating temperature: 5ºC - 35ºC (indoor)
Storage temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
