Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > Intelligent Computing > Intel AI Server

Intel AI Server

Integrated Training and Inference

CPU-GPU direct connection supports up to 8 double-width 600W GPUs, meeting the needs of various AI business scenarios. Suitable for applications in artificial intelligence, scientific computing, cloud computing, virtualization, big data analysis, and digital twins.

Applicable Solutions

Artificial Intelligence ∣ Scientific Computing ∣ Cloud Computing ∣ Virtualization ∣ Big Data Analysis ∣ Digital Twins

Add to Compare

Product Overview Product Specifications Relevant Information

New Architecture, Extreme Performance

Supports 1 or 2 fourth or fifth-generation Intel® Xeon® Scalable processors; with the latest DDR5 and PCIe 5.0 technologies, accelerating data transfer rates; direct GPU-CPU connection, delivering extreme multi-GPU computing power.

Flexible Topology, Key Applications

Supports direct CPU-GPU connection, accommodating up to 8 dual-width 600W GPUs for high-speed, stable operation; supports different CPU-GPU interconnect topologies such as common and performance modes, suitable for more application scenarios.

Rich Ecosystem, Stable and Reliable

Compatible with both international and domestic AI accelerator cards; redundant design for key system components, modular design for functional parts to enhance product reliability and maintainability; supports intelligent remote management and fault diagnosis, ensuring 24/7 high-efficiency stable operation.

System Model	SY4108G-D12R-G4
Processor	Supports 1 or 2 fourth/fifth-generation Intel® Xeon® Scalable processors, with a maximum TDP of 350W.
Chipset	Intel® C741 series server-specific chipset.
GPU Card	Up to 8 double-width 600W GPUs
Memory	32 DDR5 memory slots, supporting DDR5 4400/4800/5600MHz memory.
Storage Controller	2 Slimline 4x interfaces (SATA), 2 M.2 slots (2280/22110 size, SATA/PCIe 3.0 x1)
Storage	12 hot-swappable 3.5"/2.5" SAS/SATA/NVMe drives
I/O Ports	Front: 2 USB 3.0, 1 VGA Rear: 1 serial port, 2 USB 3.0 ports, 1 VGA, 1 RJ45 management port (optional addition of 2 x 10G RJ45 service network ports)
PCIe Expansion	Up to 13 PCIe expansion slots (OCP 3.0 card can be optionally configured as PCIe 5.0 x8 or x16, which is mutually exclusive with one of the PCIe5.0 standard single-width slots)
Power Supply	3+1 or 2+2 redundancy (2000W/2200W/2600W/3200W)
Fan	Standard 12 x 6056 hot-swappable N+1 redundant fans
Management	1 dedicated RJ45 management network port
Security	Supports TPM 2.0 module, chassis intrusion alarm, and BMC/BIOS redundancy
Operating System	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware ESXi, etc.
Server Size	176.5mm (H) x 444mm (W) x 850mm (D)
Working Temperature	Operating Temperature: 5ºC - 35ºC (without direct sunlight); Storage Temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
