Intel AI Server

Integrated Training and Inference

The CPU-GPU switch expansion solution supports a variety of AI acceleration cards, catering to diverse application needs in various AI business scenarios. It is suitable for applications such as cloud computing, virtualization, big data analytics, digital twins, and deep learning.

Applicable Solutions:

Cloud Computing ∣ Virtualization ∣ Big Data Analytics ∣ Digital Twins ∣ Deep Learning

Add to Compare

Product Overview Product Specifications Relevant Information

New Platform Technology

Supports 1 or 2 Intel® Xeon® Scalable processors of the fourth or fifth generation. Accommodates 16 DDR5 4400/4800/5600MT/s ECC memory modules, boosting memory bandwidth by 75%. Backed by the latest CXL and PCIe 5.0 technologies, accelerating data transfer rates.

Rich Expansion Performance

With the CPU-GPU Switch expansion solution, it can accommodate up to 10*600W double-width GPU cards for high-speed and stable operation. The system supports a maximum of 19 PCIe expansion slots.

Stable Product Performance

Compatible with AI acceleration cards from both foreign and domestic brands; features redundant design for critical system components and modular design for functional parts, enhancing product reliability and maintainability; supports intelligent remote management, remote fault diagnosis, intelligent fault isolation, ensuring efficient and stable operation 24/7.

System Model	AS4110G-D04R-G4
Processor	Supports 1 or 2 Intel® Xeon® Scalable processors of the fourth or fifth generation, with a maximum TDP support of 350W.
GPU Card	Supports up to 10*600W dual-width GPUs
Memory	16 DDR5 memory slots, supporting DDR5 4400/4800/5600MHz
Storage Controller	3SLIMSAS interfaces (SFF8643), 22280/22110 size M.2 (NVME)
Storage	4 hot-swappable 3.5/2.5" SATA/SAS hard drives and 4*2.5" SATA/SAS or 4 U.2 hard drives
I/O Ports	Front: 2x USB 3.0, 1x VGA Rear: 1x serial port, 2x USB 3.0 ports, 2x USB 2.0 ports, 1x VGA, 1x RJ45 management port, 2x RJ45 Gigabit network ports
PCIe Expansion	Rear PCIe Slot: 5x full-length half-height single-width, supporting up to 9x full-length half-height single-width Front PCIe Slot: 10x full-length full-height double-width
Power Supply	3+1 redundant (2000W/2200W/2600W/3200W)
Fan	Comes standard with 11 hot-swappable 8038 fans
Management	1 dedicated RJ45 management port
Security	Supports TPM2.0 module
Operating System	Microsoft Windows Server、RedHatEnterprise Linux 、SUSE Linux Enterprise Server
Server Size	176.5mm (H) x 433mm (W) x 850mm (D)
Working Temperature	Operating temperature: 5°C - 35°C (without direct sunlight); Storage temperature: -40°C - 70°C

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
