Intel AI Server

High Performance 10 Card AI Inference Server

A 10-card AI inference server that meets high-performance requirements is designed and developed based on the Intel® Xeon® Scalable processor platform. It supports 10 computing acceleration inference cards in a 2U space. This product reflects the integration of performance, scalability and density.

Applicable solution

Add to Compare

Product Overview Product Specifications Relevant Information

Supports one or two 1st and 2nd generation Intel® Xeon® Scalable series processors
Supports 12 DDR4 memory slots with memory frequencies of 2133/2400/2666/2933MHz, with a maximum memory capacity of up to 1.5TB
Onboard 2 PCIe3.0X2 M.2 slots (size 2280) to meet cache requirements
Supports 10 PCIe3.0 high-speed expansion slots, providing rich expansion performance

Comprehensive Performance Enhancement

Supports 1 or 2 Intel Xeon Scalable processors with a maximum power consumption of 205W; 12 DDR4 RECC DIMM/LRDIMM memory slots with a maximum memory capacity of up to 1.5TB.

Outstanding Storage and Expansion Capability

Supports up to 12 hot-swappable 3.5"/2.5" SATA/SAS3.0 hard drives, providing users with extensive data storage capacity; supports up to 10 PCIe expansion slots to meet expansion needs.

Superb Integrated Computing Power

2 Intel Xeon Scalable processors offer powerful AI inference capabilities; direct GPU connectivity reduces communication latency, resulting in explosive computing power.

Excellent Networking and Management Performance

Onboard Ethernet controllers provide reliable and fast network connections. It offers iKVM (KVM over Ethernet) remote management capabilities, along with a dedicated Gigabit management port, enabling remote management through a keyboard, monitor, and mouse. This allows real-time monitoring and operations, including power on/off, to ensure timely system maintenance by system administrators.

System Model	SY2110G-D12R
Processor	1 or 2 1st/2nd generation Intel® Xeon® Scalable processors
Chipset	Intel® C621 series dedicated processor chipset
GPU Card	Supports 8 T4, A10 and other single-width, full-length, half-height cards
Memory	12 DDR4 memory slots, support DDR4 2400/2666/2933MHz LRDIMM/RDIMM
Storage Controller	Internal PCH supports RAID 0\1\10&5 (for Windows only)
Storage	Front port: 12x 3.5"/2.5" SAS/SATA HDD/SSD
Network	Onboard 2 Gigabit RJ45 network ports
I/O Ports	Front port: 2 USB3.0 Rear: 1 VGA, 2 USB3.0, 1 management network port, 2 RJ45 network ports
PCIe Expansion	up to 10 PCIe expansion slots Onboard: 1 8X slimline interface, 2 PCIe3.0X2 M.2 (2280)
GPU Quantity	10 half-height half-length single-width GPUs
Power Supply	1200W, 1300W, 1600W, 2000W, 2200W hot-swap 1+1 redundant power supply
Fan	Standard 4x 8038 hot-swap fans
Management	IPMI2.0
Security	TPM/TCM (optional)；Chassis open intrusion detection (optional); Locked upper cover of chassis
Operating System	Microsoft Windows Server、Red Hat Enterprise Linux、 SUSE Linux Enterprise Server、CentOS、Ubuntu
Server Size	695 x 433 x 87.6mm (D x W x H)
Working Temperature	Operating temperature: 5ºC - 35ºC (indoor) Storage temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
