Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Storage Server > High-Density Storage Server

High-Density Storage Server

General Storage

Delivers powerful computing performance with large-capacity storage expansion

Supports 2 × 4th/5th Gen Intel® Xeon® Scalable processors, MAX TDP 350W; supports 32 DDR5 memory slots, up to DDR5-5600 MHz

Applicable Solutions

Warm Data Storage ∣ Data Backup ∣ Data Archiving ∣ Big Data Analytics ∣ Disaster Recovery

Add to Compare

Product Overview Product Specifications Relevant Information

New Architecture, Ultimate Performance

4U dual-socket rackmount, supports 60 × 3.5-inch SAS/SATA drives; supports 2 × 4th/5th Gen Intel® Xeon® Scalable processors; latest DDR5 and PCIe 5.0 technologies accelerate data transfer speeds

Flexible Topology, Critical Applications

Supports 7 PCIe standard slots including 2 OCP 3.0 slots; supports 4 M.2 SSDs including 2 onboard M.2 SATA SSDs; low power consumption, strong scalability, high reliability, easy management, and easy deployment

Rich Ecosystem, Stable and Reliable

Supports IPMI 2.0; redundant design for key system components, modular functional modules enhance reliability and maintainability; supports intelligent remote management and remote fault diagnosis, ensuring 24×7 efficient and stable operation

System Model	SL401-D60R-G4
Processor	Supports 2 × 4th/5th Gen Intel® Xeon® Scalable processors, MAX TDP 350W
Chipset	Intel® C741 Series server chipset
Memory	32 memory slots; supports 32 DDR5 RDIMM, up to 5600 MHz
Storage Controller	RAID controller, SAS controller; onboard PCH supports 12 × SATA interfaces; Intel onboard NVMe controller
Storage	Front: 10 × 2.5-inch SAS/SATA/NVMe drives Internal: 60 × 3.5-inch SAS/SATA drives, Hot-Swap; 4 × M.2 (2280/22110)
Network	Optional OCP 3.0 NIC; optional 1/10/25/40/100/200G PCIe standard NIC
I/O Ports	Front: 2 × USB 2.0 Rear: 2 × USB 3.0, 1 × VGA, 1 × serial port, 1 × RJ45 management port Internal: 1 × USB 2.0
PCIe Expansion	7 × PCIe expansion slots including 2 × OCP 3.0 slots
Power Supply	Supports 4 power modules, optional 1300W / 1600W / 2000W CRPS power supplies, Hot-Swap, N+1 redundancy
Fan	7 × 4056 Hot-Swap N+1 redundant Fan
Security	Administrator password, TPM 2.0, chassis intrusion alarm
Operating System	Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu, VMware ESXi, etc.
Server Size	175.4mm (H) x 448mm (W) x 899mm (D)
Working Temperature	5℃～35℃

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
