Intelligent Computing Center

Gooxi Has Established a Robust Foundational Support for AI Inference and Training, Accelerating the Dawn of an Intelligent Era

AMD AI Server

Exceptional Performance, Flexible Expansion, Outstanding Ecosystem, High Reliability

Exceptional Performance, Flexible Expansion, Outstanding Ecosystem, High Reliability

Supports 2 AMD EPYC Milan series processors, compatible with AMD EPYC Rome series processors, with a maximum TDP of 280W. Supports 32 DDR4 memory slots, with frequency support up to 3200MHz. CPU-GPU direct connection configuration, maximum support for 13 PCIe 4.0 slots, configurable with 8 dual-width, full-height, full-length GPUs. Supports 12*3.5"/2.5" SATA/SAS/U.2 hard drives, meeting high-speed transmission and data storage needs.

Applicable Solutions

Artificial Intelligence∣Cloud Computing∣Virtualization∣Big Data Analysis∣Digital Twin

Product Overview Product Specifications Relevant Information


  • Supports 2 AMD EPYC Milan series processors, compatible with AMD EPYC Rome series processors, with a maximum TDP of 280W.
  • CPU-GPU direct connection configuration, maximum support for 13 PCIe 4.0 slots, configurable with 8 dual-width, full-height, full-length GPUs.
  • Supports 12*3.5"/2.5" SATA/SAS/U.2 hard drives, meeting high-speed transmission and data storage needs.




    Cutting-Edge Architecture for Superior Performance

    Supports two high-performance AMD EPYC 7003/7002 series processors;CPU-GPU direct connection communication significantly reduces latency, enabling algorithms to extract maximum performance.

    Flexible Expansion to Meet Diverse Needs

    Supports up to 13 PCIe expansion slots and can accommodate 8 dual-width, full-height, full-length GPUs, catering to a variety of customer needs across multiple scenarios; Supports the configuration of 12*3.5"/2.5" SATA/SAS/U.2 hard drives to meet high-speed data transfer and storage demands.

    Robust Ecosystem Offering Comprehensive Solutions

    Compatible with a range of mainstream AI accelerator cards and leading deep learning frameworks; A well-established ecosystem provides application solutions for diverse scenarios.

    High Reliability Ensures System Stability

    Redundant designs for critical system components enhance product reliability and maintainability; Supports intelligent remote management and smart remote fault diagnosis, ensuring efficient and stable operation of the product.


System Model SYR4108G-D12R-G3
Processor Supports 2 AMD EPYC 7003/7002 Series Processors
GPU Card Up to 8 dual-width, full-height, full-length GPUs
Memory Supports 32 DDR4 memory slots, with frequency support up to 3200MHz
Storage Supports 12 hot-swappable 3.5"/2.5" SAS/SATA/NVMe drives
Network Onboard 2 x 1GbE
I/O Ports Front: 2 USB 3.0
Rear: 1 VGA, 2 USB 3.1, 1 Management Network Port, 1 Serial Port, 1 dedicated RJ45 management network port
PCIe Expansion Onboard 19 PCIe4.0 MCIOs (X8), 2 Simline 4i
Supports up to 8 PCIe 4.0 dual-width, full-height, f
GPU Quantity 8 dual-width, full-height, full-length GPUs
Power Supply 2000W/2200W/2600W CRPS 3+1 Redundant Power (adapted to actual power needs)
Fan 12x 6056 hot-swappable N+1 redundant fans (23000±10% RPM)
Management 1 dedicated RJ45 management network port
IPMI2.0
Security Supports TPM
Operating System Microsoft Windows Server, Red Hat Enterprise Linux, SUSE Linux Enterprise Server, CentOS, Ubuntu
Server Size 850mm*444.4mm*176.4mm(D * W * H)
Working Temperature Operating Temperature: 5ºC - 35ºC (without direct sunlight)
Storage Temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
