Flagship Dual-Socket Server, Strong Scalability with Massive Storage

Current location：

Home > Products > Product List > General Computing > AMD > Milan > Single-Socket Server

Single-Socket Server

Storage-Compute Convergence

Supports 1 AMD EPYC 7003 series, compatible with AMD EPYC 7002 & 7001 series / 16 DDR4 slots, support 2400/2666/2933MHz DDR4 memory / Supports 24 hot-swap SAS/SATA (HDD/SSD)

Applicable solution

cloud computing, Virtualization, Big Data Processing

Add to Compare

Product Overview Product Specifications Relevant Information

Modular design

General rackmount chassis; a variety of modular rear windows for rapid response to customer needs; fans, power supplies, and hard drives are all modular designed to improve system reliability and heat dissipation, and facilitate future maintenance.

Strong scalability

Supports 10 PCle4.0/3.0 high-speed expansion slots to provide rich expansion capabilities. Multiple 12Gb SAS/SATA adaptive backplanes are available, offering flexibility and convenience. Customized expansion requirements are available for customers via adapter cards.

High performance

Support single/dual-socket AMD Milan EPYC 7003 processors, based on Zen 3 cores, each core has up to 32MB of L3 cache, 19% single-core performance improvement, 12Gb SAS backplane supports 1~4 double-width high power consumption GPU; support 16 dual-channel DDR4/2666/2933 memory slots. Motherboard supports NVMe(M.2) cache interface to meet high computing requirements for cloud computing, big data, and virtual computing.

Intelligent power supply and temperature control

Adopt 1+1 redundant power supply, support hot-swap replacement, and ensure the stability of the system; adopt intelligent temperature-controlled fan module, support hot-swap replacement, and has excellent shock resistance design.

System Model	ASR401-S24RE
Processor	Supports 1 AMD EPYC 7003 series, compatible with AMD EPYC 7002 & 7001 series
Chipset	/
Memory	16 DDR4 slots, support 2400/2666/2933MHz DDR4 memory
Storage Controller	1 M.2 (PCIe x 4) port 2 MiniSAS HD ports
Storage	Front: 24x 3.5"/2.5" SAS/SATA hot-swap hard drives Rear: Optional 2x 2.5" SAS/SATA/NVMe hot-swap hard drives
Network	2x 1GbE (RJ45) onboard
I/O Ports	Front: 2 USB3.0 Rear: 1 VGA, 1 COM port, 2 USB3.0, 1 management network port, 2 RJ45 network ports
PCIe Expansion	Supports 6 PCIe x8 and 4 PCIe x16
Power Supply	Support 550W, 800W, 1300W, 1600W, 2200W redundant power (adapt according to the actual power)
Fan	Standard 8x 8038 hot-swap fans
Management	1 dedicated RJ45 management network port IPMI2.0
Security	Support TPM module
Operating System	Microsoft Windows Server、Red Hat Enterprise Linux、 SUSE Linux Enterprise Server、CentOS、Ubuntu
Server Size	695 x 433.4 x 176.5mm (D x W x H)
Working Temperature	Operating temperature: 5ºC - 35ºC (indoor) Storage temperature: -40ºC - 70ºC

Please note that the above specifications are subject to change without prior notice. (Gooxi reserves the right for the final interpretation)
